Filament 3DGence PEEK Natural
Filament 3DGence PEEK Natural
Filament 3DGence PEEK Natural
Filament 3DGence PEEK Natural
Filament 3DGence PEEK Natural
Filament 3DGence PEEK Natural

Filament 3DGence PEEK Natural

  • Weight: 0,5 kg
Weight
Size
565,80 €
incl. VAT / pc.
Regular price / pc.
of
Product unavailable
Product unavailable
14 days for returns
This product is not available in a stationary store
Safe shopping
Product sold out
You will receive an email notification from us when the product is available again.
Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.
Contact details entered above are not used to send newsletters or other advertisements. When you sign up to be notified, you hereby agree to receive only a one-time notification of a product re-availability.

Filament 3DGence PEEK Natural

Polyether Ether Ketone (PEEK) is one of the most desired high-performance polymers. Exceptional mechanical and thermal properties and high chemical resistance make PEEK to be considered as a substitution for aluminium.

PEEK is one of the strongest material that can be used on FFF 3D printers. The filament perfectly combines good sliding properties, mechanical strength and resistance to high temperatures. Perfect for lightweight and strong applications.



Printing Recommendations:

PEEK should be warmed up each time before using by placing it at 75°C for about 24 hours. You can use the printer working chamber or a dedicated heat-drying dryer for this purpose. Even a small amount of moisture in the material will adversely affect the mechanical parameters and the quality of the model – air bubbles will appear on the walls.

It should be taken into account in the design process that the minimum cross-section in the model should not be less than 25 mm2. The minimum thickness of the printed wall without losing its strength is 2 mm. It is possible to print thinner walls, but their mechanical strength will be significantly reduced.

PEEK can be used together with the 3DGence ESM-10 the first soluble support for high-performance polymers on 3DGence INDUSTRY F340.

Applications:

  • Elements of machines and devices
  • Elements of aircraft interiors
  • Automotive
  • Medical applications
  • Typical applications include the automotive, marine, nuclear, oil-well, electronics, medical, and aerospace industries
To download
Brand
Symbol
F01302050200.50
Producer code
5908216294273
Material
PEEK
Diameter
1.75 mm
Weight
0.5 kg
Colour
Natural
Compatibility
INDUSTRY F421 + module M500
INDUSTRY F421 + module M500+
INDUSTRY F350 + module M500
INDUSTRY F350 + module M500+
INDUSTRY F340 + module HTmax
INDUSTRY F340 + module HTmax+
EAN
5908216294273
Mechanical properties
Tensile Strength
105 MPa
Young’s Modulus
4,1 GPa
Bending module
3,9 GPa
Charpy
14 kJ/m2
Elongation
30%
3D printing conditions on 3DGence devices
Extrusion
360 - 400°C
Bed Temperature
120°C
3DGence Certified Material Base
Yes
